The T-80 is a main battle tank (MBT) designed and manufactured in the former Soviet Union. A development of the T-64, it entered service in 1976 and was the first production tank to be equipped with a gas turbine engine for main propulsion (the Stridsvagn 103 only used a supplementary gas turbine by 1971). The T-80U was last produced in a factory in Omsk, Russia, while the T-80UD and further-developed T-84 continue to be produced in Ukraine. The T-80 and its variants are in service in Belarus, Cyprus, Kazakhstan,[9] Pakistan, Russia, South Korea, and Ukraine. The chief designer of the T-80 was the Russian engineer Nikolay Popov.[10]
Development history
The project to build the first Soviet turbine powered tank began in 1949. Its designer was A. Ch. Starostienko, who worked at the Leningrad Kirov Plant (LKZ). The tank was never built because available turbine engines were of very poor quality. In 1955 at the same plant, under guidance of G. A. Ogloblin, two prototype 1,000 hp (746 kW) turbine engine were built. Two years later a team led by the famous heavy tank designer Ż. J. Kotin constructed two prototypes of the Ob'yekt 278 tank. Both were hybrids of the IS-7 and the T-10 heavy tanks, powered by the GTD-1 turbine engine, weighing 53.5 tonnes and armed with the M65 130 mm tank gun. The turbine engine allowed the tank to reach a maximum speed of 57.3 km/h (35.6 mph) but with only 1950 liters of fuel onboard, range was a mere 300 km (190 mi). The two tanks were considered experimental vehicles and work on them eventually ceased. In 1963, the Morozov Design Bureau designed the T-64 and T-64T tanks. It used a GTD-3TL turbine engine which generated 700 hp (522 kW). The tank was tested until 1965. At the same time in Uralvagonzavod a design team under the guidance of L. N. Karcew created the Ob'yekt 167T tank. It used the GTD-3T turbine engine which supplied 801 hp (597 kW).[11]
In 1966 the experimental Ob'yekt 288 rocket tank, powered by two aerial GTD-350 turbine engines with a combined power of 691 hp (515 kW), was first built. Trials indicated that twin propulsion was no better than the turbine engine which had been in development since 1968 at KB-3 of the Kirov Plant (LKZ) and at WNII Trans Masz. The tank from LKZ equipped with this turbine engine was designed by Nikolay Popov. It was constructed in 1969 and designated Ob'yekt 219 SP1. It was renamed the T-64T, and was powered by a GTD-1000T multi-fuel gas turbine engine producing up to 1000 hp (746 kW). During the trials it became clear that the increased weight and dynamic characteristics required a complete redesign of the vehicle's caterpillar track system. The second prototype, designated Ob'yekt 219 SP2, received bigger drive sprockets and return rollers. The number of wheels was increased from four to five. The construction of the turret was altered to use the same compartment, 125 mm 2A46 tank gun, auto loader and placement of ammunition as the T-64A. Some additional equipment was also scavenged from the T-64A. The LKZ plant built a series of prototypes based on Ob'yekt 219 SP2. After seven years of upgrades, the tank became the T-80.[12]
Description
The T-80 is similar in layout to the T-64; the driver's compartment is on the centreline at the front, the two man turret is in the centre - with gunner on the left and commander on the right, and the engine is rear mounted.[13] Overall, its shape is also very similar to the T-64. The original T-80 design uses a 1,000 horsepower gas turbine instead of a 750 horsepower diesel engine, although some later variants of the T-80 revert to diesel engine usage. The gearbox is different, with 5 forward and 1 reverse, instead of 7 forward and 1 reverse. Suspension reverts from pneumatic to torsion bar, with six forged steel-aluminium rubber-tyred road wheels on each side, with the tracks driven by rear sprockets.[13] The glacis is of laminate armour, the turret is armoured steel; housing the same 125 mm 2A46 smoothbore gun as the T-72, which can fire anti tank guided missiles as well as regular ordnance.[13] The tracks are slightly wider and longer than on the T-64 giving lower ground pressure.[13]
The main gun is fed by the Korzina automatic loader. This holds up to 28 rounds of two-part ammunition in a carousel located under the turret floor.[14] Additional ammunition is stored within the turret. The ammunition comprises the projectile (APFSDS, HEAT or HE-Frag) plus the propellant charge, or the two part missile.[14] The autoloader itself is an effective, reliable, combat tested system which has been in use since the mid-1960s. The propellant charge is held inside a semi-combustible cartridge case made of a highly flammable material - this is consumed in the breech during firing, except for a small metal baseplate.[14]
A disadvantage highlighted during combat in Chechnya was the vulnerability of the T-80BV to catastrophic explosion.[14] The reason given by US and Russian experts is the vulnerability of stored semi-combustible propellant charges and missiles when contacted by the molten metal jet from the penetration of a HEAT warhead, causing the entire ammunition load to explode.[14] This vulnerability may be addressed in later models. When Western tank designs changed from non-combustible propellant cartridges to semi-combustible, they tended to separate ammunition stowage from the crew compartment with armoured blast doors, and provided 'blow-out' panels to redirect the force and fire of exploding ammunition away from the crew compartment.[14]
The autoloader speed is from 7.1 seconds to 19.5 s to load the main weapon, depending on the initial position of autoloader carousel.
Another perceived design flaw is the small angle of depression for the main gun, meaning it is limited in the hull-down positions that the tank can fire from. However, the built-in entrenching blade equipped T-80 can create an excellent capriot in less than 15 minutes. The latest T-80 variant in service, the T-84 Oplot, has an entirely new turret with armoured ammunition compartment, all but eliminating the possibility of catastrophic ammunition cook-off.
Production history
This T-80BV (a monument in St Petersburg) has reactive armour adapted to its turret and hull. The later T-80U has a large applique of explosive reactive armour installed — providing higher crew and tank survivability than prior models.The T-80 was confused with the Soviet T-72 by some Western analysts, but the T-80 and T-72 are mechanically very different. They are the products of different design bureaus; the T-80 is from the SKB-2 design bureau of the Kirov Factory (LKZ) in Leningrad while the T-72 is from the Uralvagonzavod factory in Nizhny Tagil, Russia. They are similar in superficial appearance, but the T-80 is based on the earlier T-64, while incorporating features from the T-72, which was a complementary design.[15]
The T-64 was the earlier offering of the Morozov Design Bureau (KMDB), a high-technology main battle tank designed to replace the obsolescent IS-3 and T-10 heavy tanks, used in the Red Army's independent tank units. The T-72 was intended to be a tank mass-produced to equip the bulk of the Soviet Motor Rifle units, and for sale to export partners and eastern-bloc satellite states. The mechanically simpler T-72 is simpler to manufacture, and easier to service in the field. Western analysts for many years denied the usage of gas turbines as main propulsion. From a long distance T-64, T-72 and T-80 look alike even though the T-80 is 90 cm longer than the T-64.[9]
The T-64's story continues in the T-80. The Leningrad design bureau improved upon the earlier design, introducing a gas turbine engine in the original model, and incorporating suspension components of the T-72. This gave the tank a high power-to-weight ratio and made it easily the most mobile tank in service, albeit with acute range problems, as the turbine consumed fuel rapidly, even at engine idle. (Morozov's subsequent parallel development of the T-80UD replaced the gas turbine with a commercial turbo-diesel, to decrease fuel consumption and maintenance.) In comparison to its anticipated opponent, the M1 has a larger 1,500 hp (1,120 kW) gas turbine, but weighs 61 tons compared to the T-80s 42.6 tons, so it has a worse hp/t ratio of 24.5 compared to 27.1 and is less maneuverable than the T-80 (with GT). The T-80 can fire the same 9K112 Kobra (AT-8 Songster) anti-tank guided missile through the main gun as the T-64.
T-80U on exhibition at the Kubinka Tank Museum.The T-80U main battle tank (1985, "U" for uluchsheniye ‘improvement’) was designed by SKB-2 in Leningrad (hull) and the Morozov Bureau (turret and armament). It is powered by the 1,250 hp (919 kW) GTD-1250 gas turbine. It is a step ahead of the GTD-1000T and GTD-1000TF engines that were installed on the previous tanks of T-80 line. This gas turbine can use jet fuels as well as diesel and low-octane gasoline, has good dynamic stability, service life, and reliability. the GTD-1250 gas turbine has a built-in automatic system of dust deposits removal. Of course it retains the T-80's high fuel consumption, which the Russian army found unacceptable during the Chechen conflicts. The T-80U is protected by a new generation of explosive reactive armour called Kontakt-5, integrated into the design of the turret and hull, and Brod-M deep wading equipment. It can fire the new 9M119 Refleks (AT-11 Sniper) guided missile. The remotely controlled commander's machine gun is replaced by a more flexible pintle-mounted one.
The T-80U(M) of the 1990s introduced the TO1-PO2 Agava gunner's thermal imaging sight and 9M119M Refleks-M guided missile, and later an improved 2A46M-4 version of the 125 mm gun and 1G46M gunner's sight.
Recently, the Russians seem to be abandoning the T-80. Perhaps because of the turbine-powered tank's high fuel consumption, and the poor combat performance of older T-80BV tanks in Chechnya,[16] the Russian Army decided to standardize on the Uralvagonzavod factory's T-90 tank (derived from the T-72BM, but incorporating some T-80 technology), and have had some success selling it to the Indian Army. The Omsk Tank Plant in Siberia, facing a shortage of domestic orders, has sold a small number of T-80 tanks to Cyprus, South Korea, and China, and has demonstrated versions intended for export, including the T-80UM1 with active protection systems, and the advanced T-80UM2 Black Eagle concept tank. Although the T-80 production has stopped for the Russian Army, the Omsk plant still makes the tank for export.
Ukrainian T-80UD
In parallel with the T-80U, the Morozov Bureau in Ukraine developed a diesel-powered version, the T-80UD. It is powered by the 1,000-hp 6TD-1 6-cylinder multi-fuel two-stroke turbo-piston diesel engine, ensuring high fuel efficiency and a long cruising range. The engine support systems make it possible to operate the tank at ambient fuel temperatures of up to 55°C and to ford to a water depth of 1.8 m. The T-80UD shares most of the T-80U's improvements, but can be distinguished from it by a different engine deck, distinctive smoke-mortar array and turret stowage boxes, and retains the remotely-controlled commander's machine gun. About 500 T-80UD tanks were built in the Malyshev plant between 1987–91. About 300 were still at the Ukrainian factory when the Soviet Union broke up, so the T-80UD is more common in Ukrainian service than Russian.
A further improvement of the T-80UD is the Ukrainian T-84 main battle tank, including the new welded turret, 1,200-hp (895 kW) 6TD-2 engine, Kontakt-5 reactive armour, Shtora active protection system, thermal imaging sight, muzzle referencing system, and auxiliary power unit. The T-84U (1999) shows many refinements, including deeper sideskirts, modified reactive armour, a small reference radar antenna near the gunner's hatch (used to track rounds and compensate for barrel wear), and a large armoured box for the auxiliary power unit at the rear of the right fender. The T-84 Oplot (ten delivered in 2001) introduced turret-bustle ammunition storage, and the T-84-120 Yatagan has been offered for export, featuring a very large turret bustle and NATO-compatible 120 mm gun.
T-80 models
Main article: T-80 models
Main models of the T-80, built in the Soviet Union, Russia and Ukraine, with the dates they entered service.
Command tanks with additional radio equipment have K added to their designation for komandirskiy, ‘command’, for example, T-80BK is the command version of the T-80B. Versions with reactive armour have V added, for vzryvnoy, ‘explosive’, for example T-80BV. Less-expensive versions without missile capability have a figure 1 added, as T-80B1.
T-80 (1976) – Initial model, with 1,000-hp gas turbine engine, laser rangefinder, and no missile capability.
T-80B (1978) – This model had a new turret, fire-control, and autoloader allowing the firing of 9M112-1 Kobra antitank guided missile, and improved composite armour. An improved 1,100-hp engine was added in 1980, a new gun in 1982, and fittings for reactive armour in 1985.
T-80A (1982) – A move to standardization led to a single new larger and better-armoured turret being adopted for both this tank and the T-64BM, with improved fire-control.
T-80U (1985) – Further development with explosive reactive armour, gunsight, and 9K119 Refleks missile system. In 1990 a new 1,250-hp engine was installed.
T-80UD Beryoza (1987) – Ukrainian diesel version with 1,000-hp 6TD engine and remote-controlled antiaircraft machine gun.
T-84 (1999) – Further Ukrainian development of T-80UD with 1,200-hp diesel and new welded turret.
Black Eagle tank (prototype) – Several Russian prototypes shown at trade shows, with a longer chassis and extra pair of road wheels, and very large turret with separate ammunition compartment.
Service history
Soviet Union
Soviet T-80 MBT during maneuvers, 25 March 1986.
Two T-80UD MBTs on Red Square in Moscow during failed Coup d'état attempt, August 1991.The first T-80 MBTs started arriving in the tank units of the Soviet Union in the late 1970s. The first to receive them was the Group of Soviet Forces in Germany. T-80 and T-64 MBTs were to be the core of the assault groups of tank units. The fighting capabilities of these vehicles was evaluated during numerous war games and according to them if the war with NATO would start, the T-80 MBTs would reach the English Channel within 5–6 days (with the Soviet forces having the upper hand) or 2 weeks (with the NATO forces having the upper hand). Because of this they gained the nickname of "La Manche tanks" in Soviet Army. T-80 MBTs unintentionally publicly displayed their maneuverability when a battalion equipped with those tanks appeared on a highway leading to Berlin during military exercises. While there they were able to move with speed equal to that of tourist buses and Trabant cars. At the time they were classified as secret weapons. At the beginning of its service it was the most modern and effective tank in the world. The crews praised its high speed (for a tank) and ability to quickly reach battle readiness thanks to the turbine engine. This engine however had a serious flaw which was the fact that it overheated in high temperatures which is why the tanks were not sent to the hot southern regions of Soviet Union. Only the appearance of T-80UD with a diesel engine solved this problem. In 1985 there were 1,900 T-80 MBTs overall.[17] According to data publicized in Russia, 2,256 T-80 MBTs were stationed in East Germany between 1986 and 1987. NATO realized that new Soviet tanks could reach Atlantic within two weeks and because of that started to develop counter methods that could stop them. This led to sudden increase in development of anti-tank weapons including attack helicopters. In 1991 when the Soviet Union was breaking up the Soviet Army operated 4,839 different models of T-80.[18]
T-80 MBTs were never used in a way in which they were intended, large scale conventional war in Europe. It was used during political and economical changes in Russia in 1990s. In August 1991 communists and military commanders allied with them tried to overthrow Mikhail Gorbachev and regain control over the unstable Soviet Union. T-80UD tanks of the Russian 4th Guards Kantemirovskaya Tank Division drove onto the streets of Moscow but the Soviet coup attempt failed.[19][20]
Russia
T-80BV tanks on parade. The wide box on the turret roof in front of the commander's hatch is the Kobra antitank missile control.While a number of T-80 MBTs were inherited by Ukraine, Belarus and Kazakhstan, Russia still managed to save the majority of those tanks for itself. In during the 1993 Russian constitutional crisis Boris Yeltsin ordered the use of tanks against the Russian parliament which opposed him. On 4 October 1993 six T-80UD MBTs from 12th Guards Tank Regiment which is a part of 4th Kantemirowsk Guards Tank Division took positions on a bridge opposite the Russian parliament building. The building was hit 12 times, 10 by Frag-HE rounds and 2 by undercaliber AP rounds. It remains unknown whether the use of two AP rounds was a mistake made by the gunner/commander (T-80 uses an autoloader) or if he planned to use them as they could pierce through a dozen walls in order to further terrify the parliamentarians. This operation failed because soon the tanks were surrounded by a crowd of bystanders and everything started to look more like a picnic rather than a military operation. In 1995 the number of T-80 tanks increased to around 5,000 but was reduced in 1998 to 3,500. In July 1998, a T-80 drove into a square in front of the administration building of Novosmolensk and aimed its gun at the building. The tank was commanded by major Igor Bieljajew from Molinsk garrison, a part of the 22nd Army. He was motivated by several months of unpaid wages. At first the commander of the 22nd Army tried to negotiate with the major, but the negotiations failed and it was decided to tow away the major's tank using another T-80. This was prevented by the local population which allied itself with the major. As a result all of the 22nd Army's back pay was paid.[9] As of right now Russian Army has 3,044 T-80s and its variants in active service and 1,456 in reserve.[17][18][21] There are at least 460 T-80UD in service with 2nd Guards Tamanskaya Motor Rifle Division and 4th Guards Kantemirowsk Motor Rifle Division.[22] As of right now a T-80BV is on display in Kubinka Tank Museum and a T-80U is on display at an open air museum in Saratov.
Chechen wars
T-80B and T-80BV MBTs were used during the First Chechen War. This first real combat experience for T-80 MBTs was unsuccessful as they were used for capturing cities, a task for which they were not very well suited. The biggest losses were suffered during the ill-fated assault on the city of Grozny. The reasons for that included the fact that the forces selected to capture Grozny were not prepared for such an operation while the city was defended by, among others, veterans of Soviet War in Afghanistan. The T-80 tanks used in this operation either did not have reactive armour (T-80B), or it was not fitted before the start of the operation (T-80BV).
The inexperienced crews had no knowledge of the layout of the city while the AFVs that entered it were attacked by shoulder-launched anti-tank rocket propelled grenade launchers operated by the defenders hidden in cellars and on top of high buildings. The fire was directed at the least armoured points of the vehicles. The average of hits that each destroyed tank received ranged from three to six. Each tank was fired at by six or seven RPGs. A number of vehicles exploded when the autoloader with vertically placed rounds was hit: in theory it should be protected by the road wheel, but when the tank got hit on its side armour the ready-to-use ammunition exploded. Out of all AFVs that entered Grozny, 225 were destroyed in the first month alone, representing 10.23% of all the armoured vehicles committed to the campaign. [23] The T-80 performed so poorly that General-Lieutenant A. Galkin, the head of the Armor Directorate, convinced the Minister of defence after the conflict to never again procure tanks with gas-turbine engines.[24] After that T-80 MBTs were never again used to capture cities and instead supported infantry squads from a safe distance.[22]
Exported T-80s
While other kinds of Soviet Equipment, like T-72, were exported to many countries around the world, T-80, like T-64 before it, had a status of secret weapon which meant that it was not planned to be exported early on like the T-72 was.[25] Despite that Poland was negotiating with the Soviet Union about buying either T-72S or T-80 MBTs. There were also plans to start serial production of T-80 MBTs in Poland but it turned out that Polish industry wasn't yet ready to handle T-80 production. After the political changes of 1989 in Poland and the dissolution of the Soviet bloc, Polish-Soviet talks on purchase of modern tanks came to a halt. This led to Polish developing the PT-91 MBT.
United Kingdom
In 1992 United Kingdom bought a number of T-80U MBTs for purposes of defense research and development. They were not bought officially but through a specially created trading company which was supposed to deliver them to Morocco. The price of five million USD offered for each tank ensured the lack of suspicions from the Russians who realized the situation when the Moroccan Minister of Defense who was in Russia at that time in did not confirm the transaction. By then the tanks were already in British hands. Britain evaluated the tanks on their proving grounds and transferred one to the US where the Americans evaluated it on the Aberdeen Proving Ground. While evaluating the vehicle, The US and UK carefully noted any weak spots and flaws of the T-80U which assisted their agenda of preventing the Russians to successfully sell it to the countries of the Near East and the Middle East. Although the first public appearance of T-80U in Abu Dhabi in 1993 stirred some attention, no tanks were sold as a result of the British deception. In January 1994, British Secretary of State for Defence Jonathan Aitken confirmed in parliamentary debates that a Russian T-80U tank was imported for "defence research and development purposes".[26][25]
People's Republic of China
In late 1993 Russia signed a contract with PRC about purchase of 200 T-80U MBTs for evaluation. However for unknown reasons only 50 were delivered.[27][28][29]
Pakistan
Ukrainian exports of the T-80UD have been moderately successful. In 1993 and 1995 Ukraine demonstrated it to Pakistan which was looking for a new MBT. The tank was tested in Pakistan and in August 1996 Pakistan decided to buy 320 T-80UD tanks from Ukraine for $650 million in two variants: a standard Ob'yekt 478B and export Ob'yekt 478BE.[30][31][27][32] The tanks were all supposed to be delivered in 1997 however after the first batch of 15 vehicles were shipped in February 1997, Russia protested that they held the rights to the tank and that Ukraine couldn't export it.[30][27] Nearly 70% of T-80UD components were produced out side of Ukraine (mainly in Russia). Under the disguise of keeping good relations with India, one of its most important military customers, Russia withheld 2A46-2 125 mm smoothbore guns, cast turrets and other technology which forced Ukraine to make its tank industry independent.[32] It developed domestic components, including a welded turret which was in use on the new T-84. Ukraine was able to ship 20 more T-80UD tanks to Pakistan between February and May 1997.[27][30] These 35 tanks were from Ukrainian Army stocks of 52 T-80UDs; they were built in the Malyshev plant several years before but were not delivered to their original destination. Their capabilities were below the standard agreed by both Ukraine and Pakistan.[30] The contract was completed by shipping another 285 Ukrainian T-80UD MBTs between 1997 and early 2002. These had the welded turret and other manufacturing features of the T-84.[27][30]
Its been rumored that Pakistan has supplied some of its T-80UDs along with their crews to the Taliban forces fighting the legal government of Afghanistan. Pakistani government has denied taking part in such an action.[27]
Cyprus
Cyprus is the first foreign country to officially obtain T-80 tanks. Russia sold 27 T-80U and 14 T-80UK for $174 million to Cyprus in 1996. The tanks arrived in two batches. The first one consisting of 27 T-80U MBTs arrived in 1996 while the second one consisting of 14 T-80UK MBTs arrived in 1997. This significantly reinforced the army of this country the best tank of which up until then was AMX-30B2. New tanks also gave the Cypriot National Guard the edge in a possible confrontation with the Turkish Republic of Northern Cyprus. As of now Cypriot government is interested in buying Ukrainian T-84 MBTs as, in the eyes of Cyprus, the Russians have demanded too much money for their T-80 tanks.[27][33][34]
South Korea
South Korea was given 33 T-80U and 2 T-80UK tanks to pay Russian debts to South Korea incurred during the time of the USSR. The tanks came in three batches; the first was of 6 T-80Us in 1996, followed by 27 T-80Us in 1997, and finally 2 T-80UKs in 2005. Originally, 80 T-80Us were planned.[27][33]
United States
The US Government obtained one T-80U from United Kingdom. It was evaluated on Aberdeen Proving Ground.[25] In 2003 Ukraine transferred four T-80UD MBTs over to the US.[35]
Failed export attempts
Apart from Cyprus and the People's Republic of China,[27][36] Russia has also tried to export T-80 MBTs to Turkey and Greece, the armies of which were at the time looking for new tanks. These two attempts, however, have failed.[27]
